Waterproof 3 Pole Change Over Switch Reverse Socket 20A 32A 40A 63A
Description:
56SW Series Weatherproof Surface Switches are available from 250V,
10A to 500V 50A. They incorporate a positive, rotary switch action.
'ON' and 'OFF' Positions are clearly marked and there is provision
for two padlocks.
Designed to give full motor control,a unit is rated IP66,changeoverand reversing switches are housed withing single modules as part of
the overall modular conoept of the range.Earth and neytral connectores accommodating 3x6mm cables are provided with all models.reversing switches type switch mechanisms are used and therefore special configurations are available.
To provide easier wiring of our 56 Series Three Pole 50A Switch, a
deeper two gang enclosure and centrally mounted option (Cat. No.
56SW363/2), allows additional room for wiring associated with this
application.
Earth and neutral connectors accommodating 3 x 6mm2 cables are
supplied
Wiring:
1. Cables looped in and out from overhead.
2. In and out from underground
3. In and out straight through the switch.
4. Two 25mm rear knockouts are moulded in the base for surface
mounting with concealed wiring.
5. Samples provided freely.
Specifications:
Main market: Europe, Australia, Middle-east, Asia, Southeast Asia,
America, Africa
| Type | | 56SW320F/R | 56SW332C/O | 56SW340C/O | 56SW363C/O |
| Rated Operational VoltageUe(-50Hz) | V | 500 | 500 | 500 | 500 |
| Rated Operational Voltage Ue(-50Hz) | V | 660 | 660 | 660 | 660 |
| Rated Thermal Current Enclose | A | 20 | 32 | 40 | 63 |
| Cable Cross Section Solid | Min | 1 | 1 | 6 | 6 |
| Max | 6 | 6 | 10 | 10 |
| Utilization Categories |
| AC21A 415V | A | 20 | 32 | 40 | 63 |
| C23A 415V | kW | 7.5 | 11 | 15 | 22 |
| AC3 415V | A | 5.5 | 7.5 | 11 | 18.5 |
| Rated Short Time Withstand Current 1s | kA | 1.5 | 1.5 | 1.5 | 1.5 |
| Rated Short Circuit Making Capacity | kAp | 22 | 22 | 50 | 50 |
Range:
56SW110, 56SW116, 56SW120, 56SW132, 56SW210, 56SW216, 56SW220,
56S232, 56SW250, 56SW310, 56SW320, 56SW332, 56SW350, 56SW363,
56SW350/2, 56SW363/2
Application:
1, 56SW series industrial waterproof Switch is used to isolate to
ensure the safety of maintenance work.
2, The industrial switch has perfect protection to your safe for
using of electricity in the rain, dust, freezing, high temperature,
strong ultraviolet radiation and other harsh outdoor environments
demand.
3, It is suitable for any outdoor application conditions
4, It can be panel mounting on surface.
