    Nylon Material IP67 3P 4P 5P 32A Interlocked Switch Socket IEC standard

    Ask Lasest Price
    Brand Name : KRIPAL
    Model Number : UKS-J236-6
    Certification : CE
    Price : negotiable
    Payment Terms : T/T, L/C, D/P
    Supply Ability : 50000 pcs per month
    Delivery Time : 20 days and depends on ordering quantity
    • Product Details
    • Company Profile

    Nylon Material IP67 3P 4P 5P 32A Interlocked Switch Socket IEC standard

    Nylon Material IP67 3P 4P 5P 32A Interlocked Switch Socket IEC standard


    CurrentPositionVoltageColorPolesModel
    16A4h110-130VYellow2P+EUKS-J136-4
    4h110-130VYellow3P+EUKS-J146-4
    4h110-130VYellow3P+N+EUKS-J156-4
    6h220-250VBlue2P+EUKS-J136-6
    9h220-250VBlue3P+EUKS-J146-9
    9h220-250VBlue3P+N+EUKS-J156-9
    9h380-415VRed2P+EUKS-J136-9
    6h380-415VRed3P+EUKS-J146-6
    6h380-415VRed3P+N+EUKS-J156-6
    32A4h110-130VYellow2P+EUKS-J236-4
    4h110-130VYellow3P+EUKS-J246-4
    4h110-130VYellow3P+N+EUKS-J256-4
    6h220-250VBlue2P+EUKS-J236-6
    9h220-250VBlue3P+EUKS-J246-9
    9h220-250VBlue3P+N+EUKS-J256-9
    9h380-415VRed2P+EUKS-J236-9
    6h380-415VRed3P+EUKS-J246-6
    6h380-415VRed3P+N+EUKS-J256-6


    Specifications

    Rated current

    16A, 32A

    No. of poles

    2P+E,3P+E,3P+N+E

    Voltage

    110V,220V,380V,500V

    Protection degree

    IP67

    Power type

    Single phase,Three phase

    Conductor cross-sectional area (mm2)

    1.5-4(16A), 2.5-10(32A),

    Material

    NYLON,PA,PC,Copper

    Warranty

    One and a half years


    Application

    Applied to Power distribution equipment.
    Applied to power systerm.
    Applied to Construction site.
    Applied to Port and pier.
    Applied to Machinery industry.
    Applied to Large modern buildings.
    Applied to Large public space.
    Applied to Transportation equipment.


    Certification


    Packaging & Delivery

    Lead Time

    Normally 20 days after received your fund, but mostly depends on your quantity

    Leading Port

    Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly.

    Trade Term

    EXW, FOB, CIF as customer need

    Payment Term

    T/T 30% as deposit,and 70% before delivery.

    Packaging

    Neutral carton, or according to customer requirements

    Shipping

    By Air, by sea, by express
