Electrical Outlet Extension IP66 Plug Sockets For Power Connector

Description:

1, Gland Nut (with 50mm threaded cable entry)

For alternative facility termination.

Note: IP Ratings only apply to cable terminations as per wiring instructions

2, Cable Gland

Very flexible with positive grip to ensure reliable sealing

3, IP66 Rating(in accordance with AS1939)

When engaged in the 56CSC switched socket outlet, with the hydrant ring fully engaged, an

international protection rating of IP66 is achieved

4, Internal Cable Clamp

Grips two ways and is fast-fixing, preventing the cables(s) from twisting

5, Transparent Polycarbonate Body

Allows instant examinations of connections

6, Stainless steel Combination Head Screws

Easy installation and corrosion resistance

7, Sturdy Terminal Housing

For years of Reliable service and durability

Specifications:

Features:

1. Have a transparent body to allow visual inspection of connections and easy location into socket outlet/ extention coupler

2. Have wide locking ring with inbuilt rubber gasket to ensure IP66 rating and compliance to AS/NZS

standard

3. Have captive stainless steel combination head screws

4. Have internal clamp to prevent cable being pulled out or twisted

5. The ‘snap-shut’ body design means screw-less assembly, and an all-in-one cord clamp and cable means no need to remove the cable nut. The provision of two cable seals provides flexibility for small and large cables.

Protections: waterproof, UV resistance, Dust-proof, Anti-corrosion, Pollution proof.

Zhejiang Kripal Electric Co.,Ltd is one of the national new high-tech enterprises integrated of researching, producing and selling water-proof electric, low-voltage electric and new energy electric products.

Established in 1992, Kripal now is gradually becoming the influential electric manufacturer in China after many years well development.

With a great brand effect , Kripal has the completed sales and service network with its products been exported to all over the world like Europe,Australia, American,Africa, Oceania, Southeast of Asia, and district of HongKong, Macaw and Taiwan. Kripal is awarded the title of “Famous Export Brand”.

Kripal now has the factory area 12000 m2 and workers more than 500, including over 10 senior engineers, 30 professional technicists and 30 senior executives. Products pass the certification of CE, CB, UL, VDE, TUV, KEMA, SAA, SEMKO, RoHS, and China CCC as well as quality management system such as ISO9001.

Cooperated with domestic and foreign R&D institutions, Kripal successively developed more than 100 independent intellectual properties; some of them were successfully awarded the national patent for invention and utility models as its well performance. Kripal now has been selected as provincial technical research and development center and patent demonstration enterprise by government.

Kripal always adheres to the enterprise principle of “Scientific management, Independent Innovation, Coordinating Collaboration and Cultural Brand”, keep faith of “moral first”, and fulfill the core value of “double-win cooperation with customers, creating profit for company owners, getting rich together with workers, building harmony for society” and fight for the mission of “make the dream of world famous electrical brand come true”.

Workers: 650 (including workers in Taizhou factory)

Engineers: more than 30

QA/QC: more than 20

Certificate: CQC, CB, CE,VDE,UL, TUV, Semko, KEMA, SAA, ISO9001

The land space of the company: amounts to 25000m2

What we do: products’ design, mold building, production of parts (injection & punching), assembling,
                      products’ inspection, testing and etc

KRIPAL adheres to the belief - "scientific management, independent innovation, coordinating collaboration, and cultural brand" and the enterprise principle - "we are advancing every day".
