TUV 100kw Solar PV Inverter On Grid Pure Sine Wave Inverter For Photovoltaic Plant

KRIPAL has the Utility Model Patent, Design Patent and Ownership of Software Copyright for on-grid solar inverter

Grid tie solar PV inverter is one of the crucial parts in the PV system to feed the electricity to the public grid.

Thanks to its new technology and novel algorithm, KSG series grid tie inverter is one of the most efficient and

reliable grid tie inverters in the world.


Description:

1. Advanced GBT power modules

2. High conversion-efficiency, low temperature-rise, low noise, long-life design

3. Advanced MPPT algorithm, the efficiency of> 96.9%

4. Excellent Waveform Control Technology

5. Wide range of performance indicators for power

5. Advanced anti-islanding technology

6. Comprehensive fuction of system protection, high reliability design

7. CVT and MPPT model

8. Wariety of communication interfaces, multi-language LCD display

9. Programmable protection and operating parameters

10. Easy module design, installation, operation, maintenance

11. Low voltage ride through, reactive power, active regulation, And function (optional)

12. In line with the standards: EN 50178: 1997 prEN 62109-1: 2007 IEC 62103: 2003 IEC 60364-7-712: 2002 DIN VDE0126-1-1: 2006 EN 61000-6-2: 2005 EN 61000-6-4: 2007


Specifications:

COMMUNICATIONS

RS485 /RS232 interfaces

Open the cover of RS232 serial port, connect solar Inverter and computer byRS232 cable. By the way, the communication distance should be below 10m. If your computer doesn't have any RS232 port, only has USB ports, please buy a RS232-USB converter for the communication in the local market.The RS485 is used for several inverters’ communication. Ethernet cable is applied to connect each inverter herein. Only three cables in ethernet cable are applied:two signal ones and one for ground connection

Efficiency:
Based on the efficient MPPT design, Excellent inverter efficiency, provide the greatest energy conversion.


Control:
the output is in sine wave with the same frequency and phase of grid,and the waveform deriation ratio is less than 3 percent.


Monitor:
All inverters can be monitored through the remote monit-oring system in real time.


Flexibility:
grid-connected, mounted indoors or outdoors. the broad product range allows for a tailored system design.


Easy installation:
run with different power inverters and determined the phase of power grid wiring automatically,Comply with the connection requirements of power grid in defferent country by simple settings.

Zhejiang Kripal Electric Co.,Ltd is one of the national new high-tech enterprises integrated of researching, producing and selling water-proof electric, low-voltage electric and new energy electric products.

Established in 1992, Kripal now is gradually becoming the influential electric manufacturer in China after many years well development.

With a great brand effect , Kripal has the completed sales and service network with its products been exported to all over the world like Europe,Australia, American,Africa, Oceania, Southeast of Asia, and district of HongKong, Macaw and Taiwan. Kripal is awarded the title of “Famous Export Brand”.

Kripal now has the factory area 12000 m2 and workers more than 500, including over 10 senior engineers, 30 professional technicists and 30 senior executives. Products pass the certification of CE, CB, UL, VDE, TUV, KEMA, SAA, SEMKO, RoHS, and China CCC as well as quality management system such as ISO9001.

Cooperated with domestic and foreign R&D institutions, Kripal successively developed more than 100 independent intellectual properties; some of them were successfully awarded the national patent for invention and utility models as its well performance. Kripal now has been selected as provincial technical research and development center and patent demonstration enterprise by government.

Kripal always adheres to the enterprise principle of “Scientific management, Independent Innovation, Coordinating Collaboration and Cultural Brand”, keep faith of “moral first”, and fulfill the core value of “double-win cooperation with customers, creating profit for company owners, getting rich together with workers, building harmony for society” and fight for the mission of “make the dream of world famous electrical brand come true”.

Workers: 650 (including workers in Taizhou factory)

Engineers: more than 30

QA/QC: more than 20

Certificate: CQC, CB, CE,VDE,UL, TUV, Semko, KEMA, SAA, ISO9001

The land space of the company: amounts to 25000m2

What we do: products’ design, mold building, production of parts (injection & punching), assembling,
                      products’ inspection, testing and etc

KRIPAL adheres to the belief - "scientific management, independent innovation, coordinating collaboration, and cultural brand" and the enterprise principle - "we are advancing every day".
