DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard

    Buy cheap DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard from wholesalers

    Buy cheap DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard from wholesalers
    • Buy cheap DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard from wholesalers

    DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard

    Ask Lasest Price
    Brand Name : KRIPAL
    Model Number : UKM32-630
    Certification : CE, KEMA
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 50000 pcs per month
    Delivery Time : 20 days and depends on ordering quantity
    • Product Details
    • Company Profile

    DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard

    DC Molded Case Breaker For Photovoltaic System 16-1250A 500V IEC standard


    The UK,M32 series breakers is supplied with rated insulation voltage 1000V and used for circuit of 50Hz /60Hz, rated operation voltage DC 1000V or below rated operation current up to 1600A for infrequent changing over and starting of the motors. Equipped with the protection devices for over-current, short circuit and under voltage, the product is capable of preventing damage of circuits and supply units. The product conforms to IEC60947-2 standard.


    Model

    Rated current (A)

    UKM32-160

    16

    20

    25

    32

    40

    50

    63

    80

    100

    125

    160

    UKM32-250

    40

    50

    63

    80

    100

    125

    160

    200

    250

    -

    -

    UKM32-630

    300

    400

    500

    630

    -

    -

    -

    -

    -

    -

    -


    Specifications:


    TypeUKM32-160UKM32-250UKM32-630UKM32-1250
    Frame size[AF]1602506301250
    Rated curent,ln[A]16,20,25,32,40,50 63,80,100,125,16040,50,63,80 100,125,160,200,250300,400,500,630800,1000,1250
    No.of poles2*,3,42*,3,42*,3,43
    Rated operational voltage,UeAC [V]690690690690
    DC [V]500500500500
    Rated impulse withstand volatge,Uimp[kV]8888
    Rated insulationvoltage,Ui750750750750
    Rated ultimate short-circuit breaking capacity,lcu[V]NHLNHLNHLNH
    AC 50/60Hz 220/240V[kA]851002001001202001001202008585
    380/415V[kA]5085150508515065851505070
    440/460V[kA]5070130507013065851305065
    480/500V[kA]3050654265854265854050
    660/690V[kA]58101015201020353042
    DC 250V[kA]426510050851005085100
    DC(2poles in series) 500V[kA]4265100508510050851002020
    Rated short-circuit making capacity lcm
    AC 50/60Hz 220/240V[kA]1872204402202644402202644406363
    380/415V[kA]10518733010518733014318733037.552.5
    440/460V[kA]10515428610515428614318728637.548.5
    480/500V[kA]6310514388143187881431873037.5
    660/690V[kA]8141717304017407422.531.5
    Use categoryAAAA
    Implementation of standardsIEC60947-2IEC60947-2IEC60947-2IEC60947-2
    Mechanical Life (Number of operations)25000250002000010000

    Description:

    1. Thermal magnetic adjustable
    2. Double making & double breaking design
    3. Contacts: 85% AgCdo
    4. Metal parts: cooper
    5. Plastic Parts: brand-new materials

    6. High breaking capacity.

    7. Bearing Rotating shaft

    8. The max breaking capacity of each model is up to 150 kA
    9. U-type fixed contact design
    10. Don't contain any noxious substances and its manufacturing And processing are performed in

    accordance with the requirements of ISO14001.


    Advantages:


    1. Rotating shaft with bearing

    2. snap action

    3. Current-limiting capacity

    4. Modularized design

    5. Advanced magnetic field analysis

    6. Environment friendly


    Exploded view:
