Kripal Waterproof Isolator Switch IP66 250V 440V IEC standard
Product Description
| Brand Name | KRIPAL |
| Model Number | UKF2 |
| Type | Weatherproof Isolator Switch |
| Number of poles | 1P,2P,3P,4P |
| Current | 20A,35A,63A |
| Frequency | 50/60Hz |
| Protection | IP66 |
| Material | PC,Copper |
| Standard | IEC/EN60947,AS/NZS 3123:2005 |
| Identification | SAA,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Color | Gray&White |
| Warranty | One and a half years |
| Current(A) | Rated Voltage(V) | Pole(P) | Type |
| 20 | 250 | 1 | UKF2-120 |
| 440 | 2 | UKF2-220 |
| 3 | UKF2-320 |
| 4 | UKF2-420 |
| 35 | 250 | 1 | UKF2-135 |
| 440 | 2 | UKF2-235 |
| 3 | UKF2-335 |
| 4 | UKF2-435 |
| 63 | 250 | 1 | UKF2-163 |
| 440 | 2 | UKF2-263 |
| 3 | UKF2-363 |
| 4 | UKF2-463 |
Product Feature
1. The installation and the neutral point grounding pole with
double clamp screw, can effectively will all fixed to the junction
box, cable and reliable clamping, prevent the liquid leakage
2. The security is higher, the switch installed on the metal
structure with insulation cap, insulation cap on base mounting
screws, to prevent contact with electric cable.
3. Each device is equipped with threaded conduit connector and
threaded reducing pipe for connecting 25mm or 20mm conduit and nut;
Nuts must be installed to ensure IP rating.
4. Impact base and lid in almost all the installation conditions
can withstand the impact between the base and lid, base and
separated by a weather resistance and waterproof seal between the
lid.
5. For safety, use 7mm diameter holes in heavily machined cast
baffles to lock the lever during maintenance or overhaul. The deep
mounting baffle is secured to prevent accidental switch operation
of the operating handle.
6. Appearance color: The standard color of the switch is gray and
white.
Product Application
The products are widely used in smelting, chemical industry, power
and electronics, airport, railway, construction site, mine, quarry,
water supply and drainage treatment plant, automobile
manufacturing, port, wharf, shopping mall, hotel and other places.
The 'open' and 'close' positions are clearly marked and padlock
holes are provided When used as maintenance switch and safety
switch, padlock can be installed on the "closed" part; If you want
to lock in the 'open' position, you only need to lock one hole; So
as to ensure the safety of users.
